Astera – Pixel Brick Multi-Purpose Light

Astera

Battery-powered uplighter and spotlight. Multiple pixelbricks can be connected to form clusters and shapes.

SKU: WLLFLASTERAPIXBRICK Categories: , , ,

Description

In addition to being a battery-powered uplight and spotlight with 5 different beam options, multiple PixelBricks can be connected to form clusters and shapes. With about 10cm edge length and 1kg weight, it is small and lightweight while still featuring a powerful output of high-quality light which meets the highest demands of film, TV and stage clients.

Features

Uplight

PixelBrick works as a uplight which can bring stunning colors and white tones to any wall or object. Its native 13° beam can be modified with several filters.

Build Shapes

Get creative by arranging PixelBricks in geometrical shapes or build a matrix with the numerous available corner pieces. Add domes to change from beam to a pixel look.

Additional information

LED Engine

Titan LED Engine

Colors

RGBMintAmber

Total LED Power

15 W

LED Power Draw

12 W

Luminous Flux 2700K

405 Lumens

Luminous Flux 3200K

475 Lumens

Luminous Flux 5500K

395 Lumens

Light Output 2700 K @ 1m

6 178 Lux

Light Output 3200 K @ 1m

7 144 Lux

Light Output 5500 K @ 1m

5 985 Lux

CRI (Ra)/ TLCI 3200- 6500 K*

≥96

Beam Angle

13°

Field Angle

25°

Strobe

0 – 25 Hertz

Pixels

1

Battery Runtime

up to 20 hours

Battery Lifetime

70 % after 300 cycles

DC Input

24 VDC – 0.8 A

DC Connector

5.5 mm x 2.1 mm

AC Input

No

AC Connector

No

Power Consumption (max.)

20 W

Wired DMX

Yes via PWB-2-86 (FP1-PWB / FP3-DTL)

CRMX Receiver

Built-in

BluetoothBridge BTB

Built-in

Wireless Protocols

CRMX, UHF, Bluetooth, WiFi

Wireless Range

CRMX/UHF up to 300 m / 330 yds Bluetooth up to 3 m / 3.3 yds

Infrared Control

Yes

Housing Material

Aluminium

IP Rating unwired

IP65 (only with PB15-PLG)

IP Rating wired with PWB-CAB-0.2/-1.5/-5/-10/-15

IP65

Ambient Operating Temperature

0 – 40 °C / 32 – 104 °F

Weight

1.12 kg / 2.47 lbs

Dimensions (L x W x D)

91 mm x 91 mm x 94 mm / 3.6" x 3.6" x 3.7"

Mounting Options

4x Airline Tracks, 4x M5 threads, BrickBracket
