Martin – Mac Viper Performance

Martin

Full-feature framing fixture that delivers an output and performance never before seen in a fixture this size or one using so little power.

Now For Sale

This ex-hire fixture, along with other well‑maintained event and theatrical equipment, is now available for sale.

To find out more, visit our Ex‑Hires page and register your interest in used equipment.


Ex-Hire Sales


If you’d still Like to Hire this fixture, use the options below.

SKU: MLEMVHMCVIPERPR Categories: , , , , ,

Description

The MAC Viper Performance is a full-feature framing fixture that delivers an output and performance never before seen in a fixture this size or one using so little power. Unlike other fixtures in this class, the MAC Viper Performance does not forgo an iris or animation wheel – they are both included along with a framing system and rotating gobos.

The framing system consists of four shutter blades that can all individually adjust +/- 30° while the entire system can rotate +/- 55°. The exacting system can repeat each cue with great precision. When fully focused, gobos can be nicely framed with a soft edge. The MAC Viper Performance has adopted the compact form, impressive speed, superior light quality and beautiful colors that the MAC Viper Profile is renowned for and uses the same 1000-watt lamp.

  • 26000 Lumens – Excellent light quality with a very flat and uniform field and 6000K color temperature
  • 1:4 zoom – Fast zoom with auto-linked focus
  • Four shutter blades individually adjust +/- 30° while the entire system rotates +/- 55°. Repeats cues with great precision



Feature Quick View

  • 26000 Lumens – Excellent light quality with a very flat and uniform field and 6000K color temperature
  • 1:4 zoom – Fast zoom with auto-linked focus
  • Four shutter blades individually adjust +/- 30° while the entire system rotates +/- 55°. Repeats cues with great precision
  • Large aperture front lens – The 140 mm front lens exceeds the size of any other fixture in this segment for just the right fat beam look
  • 5 rotating gobos – All glass gobos with only a slight focal separation to the framing system
  • Animation wheel with continuous bi-directional rotation
  • CMY – Vibrant color mixing with a superior palette of colors including true reds, rich ambers, primary green and deep blues
  • 7-slot color wheel – Static colors and correction filters for added color choice and bump effects
  • Linear CTO – Daylight to tungsten CCT control and expansion of the CMY palette
  • Dimmer and shutter – Combined dimmer/shutter system with intensity effects, instant blackout/open and smooth fades
  • Iris – Fast and tight iris with adjustable dynamic effects
  • Strobe – Diverse strobe effects using mechanical or electronic control or in combination
  • Soft frost – A light frost leaves gobo artwork visible with a beautiful soft edge. Includes a linear focus blurring option
  • 4-facet prism – Real beam separation with rotation and index control for dynamic effects and accurate tiling



Video

Additional information

Weight 37.9 kg
Dimensions

Length:
472 mm (18.6 in.) base
566 mm (21.6 in.) head

Width:
472 mm (18.6 in.)
335 mm (13.2 in.) base

Height:
731 mm (28.8 in.) head straight up
748 mm (29.4 in.) maximum
Dynamic Effects

Color mixing: CMY, independently variable 0 – 100%
Color temperature control: CTO, variable 6000 – 3200 K
Color wheel: 7 interchangeable dichroic filters + open, indexing, continuous rotation, random color
Aerial wheel: 5 interchangeable texture/breakup gobos + open, indexing, continuous rotation and shake
Gobo animation: Interchangeable animation wheel, indexing, continuous rotation with variable speed and direction
Framing: Rotatable framing module, +/- 55°, with 4 individually controllable blades
Prism: Interchangeable 4-facet rotating prism
Iris: 0 – 100%
Frost: Variable
Mechanical dimmer/shutter: 0 – 100% continuous dimming, variable & random strobe & pulse effects, instant open & blackout
Dimming options: Choice of four dimming curves
Zoom-focus linking system: 3-zone
Zoom: Motorized
Focus: Range varies with zoom angle, from 2 m / 6 m to infinity (approx.)
Pan: 540°
Tilt: 268°
Position correction system: Absolute position monitoring
Control and Programming

16-bit control: Dimming, rotating gobos, zoom, focus, pan and tilt
Setting and addressing: Control panel with backlit graphic display and jog wheel or via DMX
DMX channels: 32/40
Receiver: Opto-isolated RS-485
Firmware update: USB memory device or USB/DMX hardware interface over DMX link
DMX compliance: USITT DMX512-A
RDM compliance: ANSI/ESTA E1.20
Optics

Zoom range: 10-44° (1:4)
Color temperature: 6000 K
Output: 26,000 lumens
Lamp

Type: 1000 W short-arc discharge
CRI (Color rendering index): >85
Average lifetime: 750 hours
Socket: PGJX36
Ballast: Electronic
Approved lamps: Osram Lok-it! 1000/PS Brilliant, Osram Lok-it! 1000W/PS VS1, Philips MSR Gold MiniFastFit 1000W
Service Utilities

Fixture identification: User-settable fixture ID number
Construction

Housing: UV-resistant fiber-reinforced composite
Color: Black
Reflector: Glass, cold light
Protection rating: IP20
Gobos

Size: E27 (Size E, max. image diameter 27 mm)
Approved material: Borosilicate 3.3 or better with dichroic or heavy matted aluminum coating (metal gobos not approved)
Outside diameter: 37.5 mm +0/- 0.2 mm (1.5 +0/- 0.01 in.)
Maximum image diameter: 27 mm (1.1 in.)
Maximum thickness: 1.1 mm +/- 0.1 mm (0.1 in. +/- 0.01 in.)
Installation

Mounting points: Eight quarter-turn locking points
Orientation: Any
Minimum distance to combustible materials: 0.3 m (1.0 ft.)
Minimum distance to illuminated surfaces: 3.4 m (11.2 ft.)
Connections

AC power input: Neutrik PowerCon
DMX and RDM data in/out: 5-pin locking XLR
USB memory devices: USB host socket
Electrical

AC power: 120-240 V nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch-mode
Typical half-cycle RMS inrush current: 16.2 A
Typical Power and Current

120 V, 60 Hz: 1225 W, 10.3 A, PF 0.999
208 V, 60 Hz: 1190 W, 5.8 A, PF 0.996
230 V, 50 Hz: 1186 W, 5.2 A, PF 0.994
240 V, 50 Hz: 1194 W, 5.0 A, PF 0.993
Measurements made at nominal voltage. Allow for a deviation of +/- 10%. PF = power factor.
Thermal

Cooling: Filtered forced air (temperature-regulated, low noise)
Maximum ambient temperature (Ta max.): 40° C (104° F)
Minimum ambient temperature (Ta min.): 5° C (41° F)
Maximum surface temperature, steady state, at 40° C ambient: 150° C (302° F)
Total heat dissipation (calculated, +/- 10% at 120 V, 60 Hz): 4180 BTU/hr
